Technical details
-
Loading limit150 kg / 330 lb
-
Min. height of rider130 cm / 51 in
-
Weight (with/without kickstand)7,4 kg / 16.3 lb
-
Box size109 x 64 x 14,5 cm (42.9 x 25.2 x 5.7 in)
-
Box weight9,8 kg / 21.6 lb
-
FrameYEDOO alloy
-
ForkYEDOO alloy
-
StemZOOM alloy
-
HandlebarYEDOO Cross alloy
-
GripsErgonomic
-
Bar endsOptional
-
HeadsetNECO alloy 1 1/8″ threaded
-
Brake leversTEKTRO ML 520 alloy
-
Brakes (front/rear)“V” TEKTRO alloy /”V” TEKTRO alloy
-
Wheels20″ / 16″
-
RimsHJC alloy double wall + CNC milled braking surface
-
HubsNOVATEC
-
Hub width (front/rear)74 / 74 mm // 2.9 / 2.9 in
-
BearingsIndustrial
-
Quick-release levers (front/rear)Yes / Yes
-
Tyres (front/rear)KENDA
-
Max. inflation (front/rear)4,6 bar / 4,6 bar
-
Preparation for bottle holder1x
-
KickstandOptional
-
Reflective elementsNo
-
Yedoo frames are protected by registered EU industrial designs. The Yedoo brand, along with the trade names of each model, are trademark protected.
-
Dimensions
-
[1] Length150 cm / 59.1 in
-
[2] Footboard40 cm / 15.7 in
-
[3] Handlebar height92 – 98 cm / 36.2 – 38.6 in
-
[4] Width of handlebars64 cm / 25.2 in
-
[5] Ride height (higher/lower position)4,5 / 6,5 cm // 1.8 / 2.6 in
-
[6] Distance between footboard and ground (higher/lower position)7,2 / 9,2 cm // 2.8 / 3.6 in
-
[7] Room for rider64 cm / 25.2 in
-
Documents, standards and certificates
-
Manual
-
Norms
-
Testing authoritySZÚ, s. p.
-
We don’t just brag that our products have performance and quality built to last – we’ve proved it by extending the full warranty to 3 YEARS
